All Geared Radial Drill Machine

All Geared Radial Drill Machine
All Geared Radial Drill Machine
Send Inquiry
Product Code : 03
Brand Name : GMC
Price And Quantity
  • Minimum Order Quantity
  • 1 Unit
  • Price
  • 50000 INR/Unit
Product Specifications
  • Condition
  • New
  • Product Type
  • Radial Drill Machine
  • Material
  • Metal
  • Computerized
  • No
  • Voltage
  • 220-380 Volt (v)
  • Power Source
  • Electric
  • Color
  • Green
Product Description

Geared Radial Drill Machine

This machine is widely used to deliver stable performance during drilling process. We take immense pleasure to introduce ourselves as a trusted manufacturer and supplier of All Geared Radial Drill Machine. Offered machine is used in woodworking, metalworking and construction applications. We manufacture this machine using high quality materials and components. All Geared Radial Drill Machine is perfect for drilling holes of different sizes and precise depths on metal or wooden surface.

Features:

  • Noise free operation
  • Easy to install and operate

Technical Specification:-

Model

GMC- 40

GMC- 50

GMC-65

GMC-75

Drill Head





Drilling capacity in steel

40 mm

50 mm

65 mm

75 mm

Drilling capacity in casting

50 mm

60 mm

75 mm

85 mm

Drilling depth

180 mm

225 mm

325 mm

355 mm

Taper Spindle Nose socket

MT-4

MT-5

MT-5

MT-6

No. of speeds

6

9

12

12

Range of spindle speed

55 - 665 r.p.m

45 -750 r.p.m

18 - 810 r.p.m

18-810 r.p.m

No. of spindle feed range

3 (0.1 to 0.2)

3 (0.1 to 0.2)

6 (0.125 to 1.25)

6 (0.125 to 1.25)

Diameter of Column sleeve

255 mm

310 mm

355 mm

405 mm

Drill Power

2 HP

3 HP

5 HP

7.5 HP

Capacity





Drilling Radius Max.

1050 mm

1450 mm

1700 mm

1900 mm

Drilling Radius Min.

375 mm

450 mm

500 mm

500 mm

Drilling Head Travers

675 mm

650 mm

1200 mm

1300 mm

Distance base plate to spindle Max.

1000 mm

1300 mm

1500 mm

1750 mm

Distance base plate to spindle Min.

225 mm

225 mm

300 mm

400 mm

Diameter of column sleeve

225 mm

310 mm

355 mm

405 mm

Working surface of base plate

900 x 680 mm

1120 x 830 mm

1500 x 1000 mm

1800 x 1150 mm

Dimension of base plate





Length X Width Height

1450 x 700 x200

1580 x 850 x 200

2250 x 1400 x 225

2650 x 1180 x225

Arm elevator motor

1 HP

2 HP

3 HP

5 HP

Standard box table

400 x 350 x 350

550 x 420 x 420

600 x 500 x 500

600 x 500 x 500

Standard Accessories:

  • Box Table
  • Electric Motors
  • Limit Switches
  • Coolant Pump
  • Electrical Control Panel
  • Optional Accessories:
  • Tilting Table
  • Machine Vice
  • Boring Attachment
  • Tapping Attachment
  • Electro Hydraulic Clamping
Trade Information
  • Payment Terms
  • Cash in Advance (CID), Cash Advance (CA), Telegraphic Transfer (T/T), Cheque
  • Supply Ability
  • 1 Unit Per Day
  • Delivery Time
  • 15-20 Days
  • Packaging Details
  • Wooden Box
  • Main Export Market(s)
  • South America, Eastern Europe, Australia, Western Europe, Africa, Middle East, North America, Central America, Asia
  • Main Domestic Market
  • All India
