Ram Turret Milling Machine

Ram Turret Milling Machine
Ram Turret Milling Machine
Send Inquiry
Product Code : 06
Price And Quantity
  • Minimum Order Quantity
  • 1 Unit
  • Price
  • 155000 INR/Unit
Product Specifications
  • Product Type
  • Ram Turret Milling Machine
  • General Use
  • For Milling Parts
  • Voltage
  • 220-380 Volt (v)
  • Feature
  • High Efficiency, High Performance
  • Color
  • Blue, Other
Product Description

Ram Turret Milling Machine

We are able to manufacture, supply and export Ram Turret Milling Machines at best price with high reliability, easy operation, and low maintenance. These machines are an ideal asset to every tool room. The Ram Turret Head can be swiveled & tilted. Licensed mechanize casting GC 275, All working surface hardened and ground, Spindle assembled with precision bearing provided high precision and cutting range

Features:

  • Easy installation
  • Easy operated
  • Alloy steel main spindle

Technical Specification:-

Machine Size (MM)

GMC 1 No.

GMC 2 No.

GMC 3 No.

Table




Working Surface Table

225 x 975

260 x 1200

325 x 1470

No. of T Slots

3

3

3

Longitudinal Travel Manuel (X)

535

670

780

Cross Travel (Y)

245

340

400

Vertical Travel (Z)

345

440

480

Power feed

520

640

785

Quill Travel

127

127

127

Head Swivel

45ƒ

45ƒ

45ƒ

Head Move Left & Right Horizontal

90Ã

90ƒ

90ƒ

Spindle




Quill Spindle Diameter

86

86

90

Head & Ram Rotate Parallel on body

360ƒ

360ƒ

360ƒ

Ram Travel

3 - 12

3 - 16

3 - 16

No. of Spindle Speed

8

8

8

Range of Speed rpm

75 to 2500

75 to 2500

75 to 2500

Spindle Taper

ISO 40

ISO 40

ISO 40

Electrical




Motor Required

1.5 HP

2 HP

3 HP

R.P.M

1440

1440

1440

Coolant Pump Motor

0.1 HP

0.1 HP

0.1 HP


Trade Information
  • Payment Terms
  • Cash in Advance (CID), Cash Advance (CA), Telegraphic Transfer (T/T), Cheque
  • Supply Ability
  • 1 Unit Per Day
  • Delivery Time
  • 15-20 Days
  • Packaging Details
  • Wooden Box
  • Main Export Market(s)
  • Australia, South America, Western Europe, Eastern Europe, Africa, Middle East, North America, Central America, Asia
  • Main Domestic Market
  • All India
